TS5204N557 incremental hollow shaft encoder replacement
.Diameter : 35mm
.Resolution : 50 - 2500 C/T with U, V,W commutation signals
.High Frequency Response : 300 kHz Max.
.-20° C to +85° C Operating Temperatures
.Standard line driver output provides
.greater noise immunity and longer
.cable capability (1km Max.)
.Typical Application : AC Servo Motor,Feed-back Device
·.Two types available : Standard Type with 14 wires & Less Wiring Type with 8 wires
.Power Supply DC +5V ± 5%, 200mA Max
.Output Circuit
.Line Driver 26LS31 (26C31)
.Source Current : 20 mA Max.
.Sink Current : 20mA Max.

Rise and Fall Time 100 nsec. Max.
